BlueKey is a wireless trigger switch that can be paired with a Windows PC as a wireless keyboard. When MultiGage software is running, every time the user pushes the BlueKey, an F9 key stroke is sent to the computer and triggers MultiGage to capture readings of connected gauges. If another software is running and accepts keyboard entry, such as Excel, device readings will be directly keyed into the active software.

BlueKey is IP67 rated for dust and water exposure, compact and portable, and comes with a wristband for easy attachment. It is powered by a replaceable CR2032 battery, and works with any of our wireless measurement instruments.

	BlueKey
Dimensions	1.41" / 35.9mm x 1.41" / 35.9mm x 0.43" / 11mm (9.84" / 250mm wristband)
IP Rating	IP67
Battery	CR2032
Battery Life	6 months
Temperature	14°F to 140°F
Compatibility	Windows

BlueKey Wireless Trigger Switch x1
CR2032 Coin Battery x1
User Manual x1

Brochure

User Manual

BlueKey Wireless Trigger Switch for Data Capture from multiple Bluetooth Dial Indicators on PC
