Motionics Wireless Rotor Runout Kit consists of a Bluetooth dial indicator BlueDial, a Bluetooth angle sensor BlueAngle and the iPad application Runout.

Users can attach BlueAngle to the end face or the circumference of a rotor with its magnetic base. While the rotor rotates, BlueAngle also rotates with it and continuously measures the rotating angle. At the same time, BlueDial can be set to measure at the edge of the rotating plane. Both sensors transmits data wirelessly to iPad. In the Runout app, displacement measurements from BlueDial and rotating angle readings from BlueAngle are matched to depict the real contour of the rotor in test.

To better visualize collected data, we embed a probe meter for BlueDial readings. Two different options of probe meters with different numbers of ticks are available for different resolution requirements. Additional, users can freely set the range of the probe meter to further adjust display resolution. An analog needle rotates while BlueDial reading changes. For BlueAngle, a rotating arrow follows the value of BlueAngle, indicating the angular position of the rotor.

Runout App can connect up to 9 displacement sensors simultaneously, allowing users to conduct runout test for 9 planes at the same time. An individual reading panel is assigned to each sensor connected without interference between each other.

Once the test session is complete, user can export test data or create and save a test report on the iPad. A local test record manager will allow future access to previous tests data and reports.

BlueDial	BD10-783	BD10-793
Measurement Range	0.5 in/12.7 mm	0.5 in/12.7 mm
Resolution	0.0005 in/0.01 mm	0.0001 in/0.001 mm
Accuracy	0.0008 in	0.00012 in
Wireless Data Rate	10 Hz	10 Hz
Wireless Transmission Range	20 m (indoors)/30 m (outdoors)	20 m (indoors)/30 m (outdoors)
Working Temperature	0 - 50 °C	0 - 50 °C
Battery	400 mAh rechargeable	400 mAh rechargeable
Battery Life	60 hrs	60 hrs

BlueAngle	Specification
Measurement Range	360 º
Resolution	0.1 º
Wireless Data Rate	50 Hz
Wireless Transmission Range	Up to 20 m
Dimensions	1.58 x 1.58 x 0.79 in
Working Temperature	0 - 50 °C
Battery	150 mAh rechargeable
Battery Life	10 hrs

iOS

The Wireless Rotor Runout Kit works with our Runout app, which automatically records both angle and displacement measurements at user-set test points, allowing users to view the real contour of a rotor. Click the icon below to view more details on the App Store or contact us for more information.

App Features

Simultaneous wireless displacement measurement and rotating angle measurement
Multiple displacement sensors connectivity (test up to 9 planes simultaneously)
Applicable to both horizontal and vertical rotors
User-defined number of test points on rotor circumference
Zero sensors remotely on the iPad
Sensor status page to show sensor signal strength, battery level and editable display name
Probe meter with adjustable range/resolution and rotating needle
Cartesian plot (angle-reading) and Polar plot
Data smoothing using moving average
Various test data exporting options (email, wireless print, AirDrop, saving to flash drive)
PDF test report with test information, machine image, test results, note, tester signature and map
Local test record manager to retrieve previous test data and reports

BlueDial x1
BlueAngle x1
USB Charging Cable x2
USB Power Adapter x2
Protective Carrying Case x1
Runout App for iPad x1
User Manual x1
iPad Mini 5 with Protective Case (Optional)
Extended Warranty (Optional)
